Prefabricated Dome House in Midcentury Design Style with and Steel Security Door
Product Details:
| Place of Origin: | Shandong, China |
| Brand Name: | xinyu |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $799.00/sets 1-24 sets |
| Payment Terms: | T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union, Cash, Escrow |
|
Detail Information |
|||
| Feature: | Waterproof, Solar Powered, Lightweight, Durable, Safe, Eco Friendly, Anti-Corrosion, Fire Resistant, Easy Operation, Easy Installation | Shape: | Rectangle |
|---|---|---|---|
| Warranty: | 1 Year | After-sale Service: | Online Technical Support |
| Application: | Steel Fabricated House, Shop, Toilet, COFFEE SHOP, Carport, PARTY, Meeting Pod, Guard House, Phone Booth, Construction Office, Accommodation, Bookstores, Booth, Smoking Pod, Hotel, Villa, Apartment, Office Building, Hospital, School, Mall, Sports Venues, L | Material: | Sandwich Panel |
| Use: | Toilet | Product Type: | Green Houses |
| Design Style: | Midcentury | Product Name: | Quick Assembly Prefabricated House |
| Usage: | Workshop Warehouse Construction Office | Color: | Blue White |
| Size: | 20FT/40FT Customized | Door: | Steel Security Door |
| Window: | Aluminum Window | Floor: | Wooden Floor |
| Wall: | 50/75/100mm Wave Sandwich Panel | Type: | Light Steel Structure Frame |
| Advantage: | Environmental Protection Low Cost Recycle | ||
Product Description
Flat roofed mobile houses use the strength of sandwich wall panels and roof panels, connected by nails, bolts, self-tapping screws, etc. to form a fixed mobile house system. The mobile house uses a light steel frame as the main structure, arranges the space with a standard module, and uses sandwich panels, PU tiles and roofing systems. It is easy to install and transport, simple and beautiful and can be reused, making temporary buildings an industrialized product.
Quality Service
1. We accept any drawings or samples to develop new products. 2. Any small problems will be solved in the shortest time. 3. We always provide relevant technical support and quick response, all your inquiries will be replied to within 12 hours. 4. We can ship within 7 days. 5. One-stop service, we can provide electrical, plumbing, toilet, shower, sink, and everything you want. 6. OEM service.
Material List For One Storey Prefabricated House | ||
Main Steel Frame | ||
Steel column | Fabricated by Q235 Steel, 80*80 or 100*100 or 120*120 or 150*150 Square Tube, alkyd paiting, two primary painting, two finish painting. | |
Triangular Steel structure roof | Fabricated by Q235 Steel, C80, C100, C120, C140 Section steel, alkyd paiting, two primary painting, two finish painting. | |
Roof Purlin | Fabricated by Q235 Steel, C80, C100, C120, C140 Section steel, alkyd paiting, two primary painting, two finish painting. | |
Ordinary bolt | 4.8S,Zincification | |
Roof and Wall | ||
Roof Panel | Insulated Steel Sandwich Panel wall Panel width: 950mm; Thickness: 50-1200mm. Powder coated Color steel on both sides: 0.4mm/0.5mm/0.6mm Insulation: Polystyrene, Rockwool or Polyurethane Density of Rockwool: 120Kg/m3 Density of Polystyrene: 12Kg/m3, 16KG/M3 20KG/M3 Density of Polyurethane: 40Kg/m3 | |
Wall Panel | Insulated Steel Sandwich Panel wall Panel width: 950mm; Thickness: 50-1200mm. Powder coated Color steel on both sides: 0.4mm/0.5mm/0.6mm Insulation: Polystyrene, Rockwool or Polyurethane Density of Rockwool: 120Kg/m3 Density of Polystyrene: 12Kg/m3, 16KG/M3 20KG/M3 Density of Polyurethane: 40Kg/m3 | |
Edge cover | 0.4mmgalvanized Color steel , angle Alu. | |
Fasteners & accessoreis | Nails\glue ect | |
Ceiling+Flooring | ||
Ceiling | 6mm gypsum board,with steel keel | |
Plywood | 18mm film faced plywood | |
Floor feather | 1.5mm PVC floor leather | |
Door and window | ||
Door | External door: Insulated with opening dimension 950*2100mm, furnished with lock with 3keys. Inner door: Insulated steel door. | |
Window | PVC window witn 4mm glass, with screem | |
Electrical System | ||
Electric cable | lighting 2.5m m2, aircondition: 4.0mm2, BV cable, solid core. Three diferent color | |
Lights | Double tube fluorescent lamp, 220V,50-60HZ | |
Switches | Single Switch, with junction box | |
Socket | 16A five hole univesal socket. | |
Power distribution cabinet | Box+breakers+earth leakage protective device | |
Plumbing System and Rain Water Drainage System As per building design | ||
Our Advantages
1. Stand heavy rain. 2. Suitable for the southeast asia market. 3. Life in spain: around 15 to 20 years. we can guarantee for 10 years. 4. Fire proof: b level. 5. Thermal conductivity: 0.042 m2·k/w. 6 . Wind load: wind speed 120 km/h. 7. Earthquake resistance: up to richter 8 or as required.
Durable and economical, etc.: Steel frame structure design, the structure adopts special cold-formed galvanized steel components, earthquake resistance level 8 and wind resistance level 12, and the service life is more than 20 years.
We can offers a complete solution for the prefabricated container houses including design, production, installation,after-sales service with multiple application such as: container office, worksite container camp, accommodation containers, storage containers, staff dormitory, Shopping mall, stores, coffee shop, display showroom container, multiple unit bathroom, portable toilet, swimming pools, etc.
1.Q: Could you design a new and unique prefab house for me? A: Of course! We have the most professional design team to integrate your demand to provide you with one-stop customization service. 2.Q: What do I need to provide to build a prefab house? A: It would be better if you could provide a sketch. If not, you just need to tell us your demands, such as area, house use, etc., and we can make the corresponding design for you. 3.Q: How to get the quotation of the project? A: If you can provide design drawings and required materials, we can quote according to your needs. Besides, If you don't have a drawing, we can also offer you a quotation after telling us the purpose and demand of your prefabricated house. 4.Q: How to control the cost of building a prefab house? A: After confirming the design plan, you can choose the corresponding building materials according to your own need since each material has its own price. 5.Q: what are the advantages of prefab house? A: It is prefabricated in the factory, which does not take up construction time on the site; it can be modularly assembled, which is convenient for transportation and can be moved to achieve recycled use. 6.Q: What are the uses of this type of house? A: It has multiple applications and can be used as hotels, offices, shops, residences, etc.
